How to Use Gabion Stone Separating Panels

Below you will find a step-by-step guide on how to use gabion stone separating panels.

• Experience Required: Low
• Tools Required: Protective gloves, Wire cutter
• Materials Required: Gabion baskets, Stone separating panel, Tying wire

Step 1) Select the Right Panel

• To select the appropriately sized panel, simply measure the length and height of the gabion you plan to use.
• This will determine the length and height of your stone separating divider.



Step 2) Position the Panel

• Place the partition inside the gabion, positioning it at the center of the basket’s depth.



Step 3) Secure the Panel at the Top

• Start securing the partition to the top of the gabion mesh on both sides using the tying wire included with your basket.



Step 4) Continue Securing

• Continue securing the panel with the tying wire, working your way down until you reach the bottom.



Step 5) Cut Off the Excess Wire

• Use wire cutters to cut any excess tying wire once the panel is fully secured.

Step 6) Fill the Back Compartment

• Start filling the back compartment with inexpensive rubble.

Step 7) Fill the Front

• Fill the front compartment with decorative stone.

Step 8) Ensure Both Compartments are Filled

• Once both compartments are filled, ensure the gabion is stable and securely fasten the lid to complete the installation.

Benefits

• Can be used to fill the back of the baskets with inexpensive rubble, reducing the overall cost.
• Requires less decorative stone to fill the gabion.
• Reduces pressure on the walls of the basket.
• Enables both hand laying and machine filling.



Tips & Warnings

• When considering how to use gabion stone separating panels, choose the appropriate panel size by measuring the length and height of the basket you plan to use.
• Fill the front compartment with either granite or limestone, depending on your preference.
• You can fill the back compartment with any material, as long as the pieces are larger than 75mm.
• For larger projects and structural retaining walls, you should use only engineer-approved stone to ensure the stability of the cage walls.
